LV429111
Trip unit - Micrologic 6.2 A - 40 A - 3 poles 3d
| Characteristics | |
| Main | |
| Range of product | NSX100...250 |
| Product or component type | Control unit |
| Circuit breaker application | Distribution |
| Poles description | 3P |
| Protected poles description | 3t |
| Network type | AC |
| Network frequency | 50/60 Hz |
| Trip unit name | Micrologic 6.2 A |
| Trip unit technology | Electronic |
| Trip unit protection functions | LSIG |
| Trip unit rating | 40 A ( 40 °C ) |
| Protection type | Ground fault protection |
| Instantaneous short-circuit protection | |
| Overload protection (long time) | |
| Short time short-circuit protection | |
| Complementary | |
| Mounting mode | Fixed |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
| Long time pick-up adjstment type Ir | Adjustable |
| Long time pick-up adjustment range | 18...40 A |
| Long time delay adjustment type | Adjustable |
| [tr] long-time delay adjustment | 0.5...16 s 6 x Ir |
| 0.35...11 s 7.2 x Ir | |
| 15...400 s 1.5 x Ir | |
| Thermal memory | 20 minutes before and after tripping |
| Short-time pick-up adjustment type Isd | Adjustable |
| [Isd] short-time pick-up adjustment range | 1.5...10 x Ir |
| Short-time delay adjustment type | Adjustable |
| [tsd] short-time delay adjustment range | 0...0.4 s |
| Instantaneous pick-up adjustment type Ii | Adjustable |
| Instantaneous pick-up adjustment range | 1.5...15 x In Compact NSX160 |
| 1.5...15 x In Compact NSX100 | |
| 1.5...12 x In Compact NSX250 | |
| Ground-fault time delay adjustment type -tg | Adjustable |
| Ground-fault pick-up adjustment type | Adjustable |
| [tg] ground-fault time delay adjustment range | 0...0.4 s |
| [Ig] ground-fault pick-up adjustment range | 0.4...1 x In |
| Zone selective interlocking ZSI | With |
| Communication of data | Demand current and power |
| Energy metering | |
| Instantaneous and demand values | |
| Maintenance indicators | |
| Maximeters/minimeters | |
| Power quality | |
| Protection and alarm settings | |
| Time-stamped histories and event tables | |
| Display type | LCD display |
| Type of measurement | Ammeter |
| Electrical data recording | Maintenance indicators |
| Environment | |
| Standards | EN 60947-2 |
| IEC 60947-2 | |
| NEMA AB1 | |
| UL 508 | |
| Product certifications | CSA |
| UL | |
| IP degree of protection | IP40 conforming to IEC 60529 |
| Pollution degree | 3 conforming to IEC 60947-1 |
| Ambient air temperature for operation | -25...70 °C |
| Ambient air temperature for storage | -40...85 °C |
| Part Number | LV429111 |
| Manufactuer | Schneider |
| Products | Moulded case breaker |
| Model | MCCB Control unit |
| Series | Merlin Gerin Compact NSX Micrologic 6.2A |
| Description | Trip unit - Micrologic 6.2 A - 40 A - 3 poles 3d |
| Condition | Schneider original new |
| Lead time | 1 week |
